Carburetor Cleaning Video

You’ll find useful resources on this page, tips, links to tools, parts, and supplies required to complete your repair. Lawnmower carburetor problems are the most common cause of starting then dying, no starts, rough running, surging engine, lack of power, hard starting.

Carburetors suffer from blockages, especially after the winter hibernation. Cleaning usually takes care of the problem, however, replacing the carburetor is often a better solution. Carburetors aren’t expensive or difficult to fit.

Before working on your mower be sure to remove the plug wire to prevent accidental starting, see “Repair Safety Video”.

Briggs & Stratton (Classic) Carb Cleaning

Starting and stopping is a sure sign your carburetor is blocked. It’s a common fault. Cleaning the carb will fix it. This video walks you through the removal, stripping, cleaning, and refitting of a very common B&S carburetor fitted to Classic/Sprint/Quattro engines.

This video may refer to surging, but don’t let that put you off, this video covers the root cause of surging – Carburetor cleaning.

Briggs & Stratton (Intek and Quantum) Carb Cleaning

This video covers the removal, cleaning, and refitting of the carburetor fitted to the Intek and Quantum engines.

Briggs & Stratton (E Series) Carb Cleaning

This video walks you through the process of cleaning your B&S E series engine carb. We’ll cover removal, teardown, clean, and reinstall.

Kohler Carb Clean

This video walks you through the process of cleaning your Kohler carburetor. We’ll cover carb removal, teardown, clean, and reinstall.

Honda Carb Clean

This video walks you through the process of cleaning your Honda carburetor. We’ll cover carb removal, teardown, clean, and reinstall.

Tools & Resources

To nail this procedure you may need the following tools, parts, and supplies.

Briggs & Stratton – Most models take from empty .65 US quarts (.6 lt.) 5W30 engine oil.

Honda engines – Most take from empty .58 US quarts (.55 lt.) of 10W30 engine oil.

Kawasaki engines – Most take from empty .6 US quarts (.6 lt.) 10W30 engine oil.

Kohler engines – Most take from empty .6 US quarts (.6 lt.) 10W30 engine oil.

For exact specs see:

Briggs & Stratton walk behind mowerOpens in a new tab.

Briggs & Stratton tractor engineOpens in a new tab.

Honda engines

Kawasaki enginesOpens in a new tab.

Kohler enginesOpens in a new tab.

WD40

Opens in a new tab.

This is first on the list for good reason, WD solves a ton of problems. I won’t work without it, because I can’t. Picture links to Amazon.com.

Ratchet Tool Set

Before we can do anything, we’ll need tools. I’ve selected this set as I own some Craftsman tools and while I have worn some out, they did do a lot of work. So I expect this set will last the occasional user quite a long time. This set carries both metric and standard sockets and that’s important because some mowers will have both types of fastener sizes. Set includes spark plug sockets. Picture links to Amazon.com.

Gas & Oil Syphon

Opens in a new tab.

You’ll find this tool really useful if you need to drain the gas tank, and you will if the gas is stale. The siphon will remove it without fuss or mess and it can be used for extracting the oil too. Picture links to Amazon.com.

Gas Line Clamp

Opens in a new tab.

Some small engines will have a gas tap, which is really handy when removing the carburetor, stops gas flowing all over the shop. However most engines won’t have one, these useful clamps simply squeeze the fuel line and prevent a spill while you perform surgery. Picture links to Amazon.com.

Carb Cleaner

Opens in a new tab.

When cleaning your carburetor you’ll need this stuff. Gumming is a sticky substance that’s hard to shift. The carb cleaner will remove it, however, if your carb is really bad, save yourself some work, go ahead and buy a new carburetor. Picture links to Amazon.com.

Cleaners

Opens in a new tab.

You’ll find these nylon brushes super useful when it comes time to clean those tiny passageways of the carburetor and jet. Use these in conjunction with the WD Carb cleaner. Picture links to Amazon.com.

Gas Stabilizer

Opens in a new tab.

Mix this with the gas when winterizing your small engine. Gas isn’t what it used to be, it goes stale, in some cases after just one month. Bad gas causes gumming and that’s a carburetor killer. A stabilizer will save you money and stress in the long run. Picture links to Amazon.com.

Gas Can

Opens in a new tab.

Briggs and Stratton refuel can. These guys got it right, I like it a lot, it offers press button control, no fuss no mess and no funnel required. Picture links to Amazon.com.

DVOM

Opens in a new tab.

Every home needs a Dvom (Digital Volt Ohm Meter). It’s used to check for continuity in lawn mower wiring, and for voltage when there’s a battery fitted. But don’t use this tool to check spark, that will kill it. I use mine every day. I have the previous model to this and it’s still doing its job. Picture links to Amazon.com.

Flywheel Puller

Opens in a new tab.

Now, this tool is a must-have if you’re removing the flywheel. Why would want to remove the flywheel Sometimes the flywheel key shears, it stops your engine from starting. The key is really cheap and it’s easy to fix when you’ve got this tool. Picture links to Amazon.com.

Tap & Die Set

Opens in a new tab.

Used to cut threads. Many flywheels are not threaded which is a right pain in the jacksie, but this Gearwrench kit makes short work of threading. I especially like the ratcheting T handles. Picture links to Amazon.com.

Ignition Tester

Opens in a new tab.

This tool is used to check both the spark plug and the coil for spark. Sure you can check the spark without the tool, but it’s not as good, the tool is designed to stress the whole ignition system. Picture links to Amazon.com.

Feeler Gauge

Opens in a new tab.

The ABN 26 blade feeler gauge set is marked in SAE and metric. You’ll need this set to adjust valve lash and is useful when setting armature/coil air gap. You can also use it to gap spark plugs. Picture links to Amazon.com.

Plug Gapper Tool

Opens in a new tab.

This tool isn’t strictly necessary if you have a feeler gauge, but it’s a lot easier to handle. If you haven’t guessed. You use this tool to check the gap of your spark plug, a simple effective tool. Picture links to Amazon.com.

Compression Tester

Opens in a new tab.

This is a compression tester, it’s fitted in the plug hole using the adaptor. The engine is cranked over and reading of how much compression the cylinder makes is captured on the gauge. A low reading can be caused by a simple fault such as a sticking valve. Picture links to Amazon.com.

Leak-down Tester

Opens in a new tab.

The OTc is a quality kit and will last many years of use. A leak-down tester will require compressed air. The tester measures how much air escapes a cylinder and helps you find weak rings, valves head gaskets, etc. Picture links to Amazon.com.

Impact Wrench

Opens in a new tab.

I love DeWalt, they make quality tools. This heavy-duty but lightweight 1/2 inch impact wrench makes short work of stubborn bolts like flywheel nuts and rusty blade fasteners. Up to 700 ft-lbs of torque on tap, I keep one in the trunk of our family car, which makes a flat almost enjoyable. Picture links to Amazon.com.

Drill/Screw Gun

Opens in a new tab.

I use a DeWalt screw gun (also a drill) in the workshop to speed up the process of removing engine covers, carburetor bolts, Armature bolts, etc. It’s a brushless motor and as tough as nails, I drove over it a few times – still works great! Batteries are interchangeable and so if you have a DeWalt product already you won’t need the battery. Picture links to Amazon.com.

Torque Wrench

Opens in a new tab.

Teng 1/2 Torque wrench, a fantastic tool I use it every day, and mine is still going strong. A torque wrench is advised for tightening components such as flywheel nuts and blades. The torque spec of these components is very important. Picture links to Amazon.com. If you are considering buying a torque wrench, definitely check out my review of Teng torque wrench.

Briggs & Stratton

Opens in a new tab.

This is a popular Hooai Carburetor fitted to walk behind mowers with Quantum engines, but check the engine codes listed. This is an Auto choke carburetor. This carburetor has a fuel feed bolt in the base of the bowl, dirt in the bolt feed hole is a common issue. Picture links to Amazon.com.

Briggs & Stratton

Opens in a new tab.

This is an original Briggs carburetor fitted to walk behind mowers. Part # 593261, these guys are made from plastic and I see lots of issues with them. The jet holes are particularly tiny and block so easily. There are a few different types and all look alike, so use part numbers to check before ordering. Picture links to Amazon.com.

Briggs & Stratton

Opens in a new tab.

This is a popular carburetor fitted to the classic range of Briggs and Stratton engines. This engine is fitted to many different walk-behind lawn mower models like MTD, TORO, Murray, Poulan, Craftsman, and many more. Picture links to Amazon.com.

Honda GCV 160

Opens in a new tab.

This is a Hooai carburetor fitted to the Honda GCV160 engine only, not the GVC190. It comes with gaskets, plugs, filters, and fuel lines. Fitting isn’t difficult, just a little tedious, take your time and some pictures of where the old gaskets are positioned and their orientation. Picture links to Amazon.com.

Honda GCV 190

Opens in a new tab.

This is a Hipa GCV 190 carburetor fitted to the Honda GCV190 engine only, not the GVC160. It comes with gaskets, plugs, filters, and fuel lines. Fitting isn’t difficult, just a little tedious, take your time and some pictures of where the old gaskets are positioned and their orientation. Picture links to Amazon.com.

Piston Stop Tool

Opens in a new tab.

Universal piston stop tool 10mm and 14mm, used to lock the crankshaft when removing and tightening the flywheel nut. Picture links to Amazon.com.
